Product Details:
|
| Material & Color:: | Aluminum Alloy & Black | Dimension: | 11.93x5.91x3.54" |
|---|---|---|---|
| Weight: | 9.37 Lbs | Frequenz: | 45~67Hz |
| Input Voltage: | 100~120Vac/200~240 Vac | Battery Type: | Lead Acid/Lithium/Li-ion Battery |
| Fan: | Intelligent Cooling Fan Controlled By Temperature And Load Current | Output: | 12V/90A |
| DC/AC Connector: | Optional Connector | Communication: | CAN, RS485, Bluetooth |
| Efficiency: | 89% | Protection: | Output Over Voltage, Output Over Current, Short Circuit, Reverse Polarity, Over-Temperature |
| Warranty: | 18 Months | Operating Temperature: | -20℃ To 40 ℃ |
| Storage Temperature: | -40 ℃ To 70 ℃ | ||
| Highlight: | 12V Forklift Battery Charger,90A Forklift Battery Charger,90A Battery Charger |
||
If you're looking to charge your forklift battery with a 12V 90A charger, our advanced charger is here to meet your needs. Let's explore how it can effectively charge your battery:
Compatibility with Various Batteries: Our charger is suitable for both lead-acid and lithium batteries. We will customize the charging curve to match your specific battery type, ensuring optimal charging performance.
Multi-Stage Charging Curve: The charger features an automatic multi-stage charging curve. This intelligent design prolongs the battery's lifespan by carefully adjusting the charging parameters at different stages, optimizing the charging process.
Stable and Energy-Efficient Design: With a current-mode half-bridge circuit topology, our charger guarantees stability, high efficiency, and energy savings. It provides a reliable and efficient charging experience while minimizing power losses.
MCU Control and PFM Technology: Equipped with MCU control and pulse frequency modulation (PFM) technology, our charger delivers high efficiency, excellent stability, and low carbon footprint. It can adapt to different battery charging curves, meeting diverse charging requirements.
Durable and Portable Design: Encased in an aluminum alloy shell, our charger combines aesthetics with durability. The sleek design not only enhances its visual appeal but also ensures long-lasting performance. It features a convenient handle for easy portability and incorporates an intelligent temperature control fan system to enhance heat dissipation efficiency.
Communication Options: Our charger supports communication protocols such as CAN, RS485, and Bluetooth. This enables seamless connectivity and control, allowing you to monitor and manage the charging process remotely.
LED Status Indicators: The charger incorporates LED lights that indicate the current working status, providing visual feedback on the charging process.
| Type | Specification | DC Voltage(Max) | (CC:A) Charging current |
Light Turning(A) | |||
| Li-ion | Lifepo4 | Lead acid | Lithium | Lead acid | |||
| UY2000 | 12V 90A | 12.6V/16.8V | 14.6V | 14.7V | 90A | 8%CC | 25%CC |
| 24V 60A | 25.2V/29.4V/33.6V | 29.2V | 29.4V | 60A | |||
| 36V 40A | 42V/46.2V | 43.8V | 44.1V | 40A | |||
| 48V 30A | 50.4V/54.6V/58.8V | 54.75V/58.4V | 58.8V | 30A | |||
| 60V 25A | 63V/67.2V/71.4V | 73V | 73.5V | 25A | |||
| 72V 20A | 79.8V/84V | 87.6V | 88.2V | 20A | |||
| 84V 18A | 88.2V | 102.2V | 107.8V | 18A | |||
| 96V 16A | 100.8V | 109.5V | 117.6V | 16A | |||
| 108V 10A | 113.4V | 120.45V | 132.3V | 10A | |||
| 120V 9A | 126V | 131.4V | 147V | 9A | |||
Product Features
1.CCM PFC + classic full-bridge configuration.
(1) Self-balancing capability.
(2) Enable from 0 voltage starting charging.
(3)With MCU, Optional configuration of RS485, CAN or Bluetooth communication function.
2.LED instrument display, indicating both voltage and current.
3.Intelligent cooling Fan controlled by temperature and load current.
4..Protection features: Overcurrent, Overvoltage, Overtemperature, Short Circuit, Reverse Polarity, Shutdown or Trickle Charge, Anti-reverse charging.
