Product Details:
|
| Material & Color: | Aluminum Alloy & Black / Sliver | Dimension: | 262x136x89 Mm |
|---|---|---|---|
| Input: | 100-240VAC | Frequen: | 47-63Hz |
| Charger Type: | Lead Acid/Lithium/Li-ion Battery | Fan: | Temperature + Load Current Double Control Fan |
| Protection: | Over Current, Over Voltage, Over Temperature, Short Circuit, Reverse Polarity, Shut Off Or Trickle And Anti-reverse Charger. | Output Voltage: | 24v |
| Adjustable Voltage: | 29.2v/29.4v/29.4v | Output Current: | 30a |
| DC/AC Connector: | Optional Connector | Efficiency: | >=92% |
| Warranty: | 18 Months | Operating Temperature: | -4 ~ 104℉（-20 ~ +40 ℃） |
| Storage Temperature: | -40 ~ 104℉（-40~ +70 ℃） | ||
| Highlight: | 24V Electric Scooter Charger,30A Electric Scooter Charger,24V Scooter Charger Waterproof |
||
IP65 Waterproof 24V 30A Lead Acid Lithium Lifepo4 Battery Charger For Surfboard
Product Description:
Are you a passionate surfer who loves riding the waves? Then you know the importance of having a reliable and efficient battery charger for your surfboard.
Water and moisture are no longer a concern with our IP65 waterproof rating. Whether you're paddling through waves, catching barrels, or enjoying the thrill of the ocean, our charger will keep your batteries fully protected.
Versatility is key when it comes to charging options. Our charger supports both lead acid and lithium Lifepo4 batteries, offering you the flexibility to choose the battery type that suits your needs. It's a reliable and powerful charging solution that ensures your surfboard is always ready to hit the water, delivering optimal performance every time.
Safety is our top priority. Our charger is equipped with advanced safety features to protect your batteries during the charging process. With built-in safeguards against overtemperature, overvoltage, overcurrent, short circuit, and reverse polarity, you can have peace of mind knowing that your batteries are charging safely and efficiently, so you can focus on catching the perfect wave.
Durability meets style in our charger's design. Crafted with high-quality materials, it's built to withstand the rigors of outdoor adventures. The sleek and modern look adds a touch of sophistication to your surfboard setup, reflecting your passion for both performance and aesthetics.
Don't let water damage or unreliable chargers hinder your surfing experience. Embrace the freedom of the IP65 Waterproof 24V 30V Lead Acid Lithium Lifepo4 Battery Charger. Ride the waves with confidence, knowing that your batteries are protected, charged, and ready to take you on your next thrilling surf session.
| ITEM | vb2430 | vb3620 | vb4815 | vb6012 | vb7210 | ||
| Output | Output voltage (V) | LFP | 29.2 | 43.8 | 58.4 | 73 | 87.6 |
| NCM | 29.4 | 42 | 54.6 | 67.2 | 84 | ||
| L-A | 29.4 | 44.1 | 58.8 | 73.5 | 88.2 | ||
| Float voltage(V) (only L-A) | 27.6 | 41.4 | 55.2 | 69 | 82.8 | ||
| Max charging current (A) | 30 | 20 | 15 | 12 | 10 | ||
| Customizable current (A) | ≤30 | ≤20 | ≤15 | ≤12 | ≤10 | ||
| Max power (W) | 882 | 882 | 882 | 882 | 882 | ||
| Rotating lamp current(A) | LFP | 2.4 | 1.6 | 1.2 | 0.96 | 0.8 | |
| NCM | 2.4 | 1.6 | 1.2 | 0.96 | 0.8 | ||
| L-A | 7.5 | 5 | 3.75 | 3 | 2.5 | ||
| Ripple voltage | ≤2%VOUTMAX | ||||||
| Input | Voltage range | v=W,100V~240VAC；v=H,200~240Vac；v=L,100~120Vac | |||||
| Frequency range | 47~63Hz | ||||||
| Power factor | PF>0.98/115VAC, PF>0.95/230VAC at full load | ||||||
| efficiency | ≥92% | ||||||
| Input current(type) | v=W,12A/115VAC,5A/230VAC；v=H,5A/230VAC；v=L,12A/115VAC | ||||||
| Vomit (type) | COLD START≤50A at 230VAC | ||||||
| Leakage current | ＜0.75m A | ||||||
Product Features:
|
Charger Model:
|
UY900S
|
Power:
|
900W
|
|
Housing:
|
Aluminium Alloy
|
Dimension:
|
262*88.5*161.8mm
|
|
Communication:
|
CAN, RS485
|
Waterproof:
|
IP65
|
|
Efficiency:
|
>=92%
|
Operating Temperature:
|
-20 to 40℃
|
|
Noise:
|
<=40dB |
Storage Temperature:
|
-40 to 70℃
|
|
Cooling:
|
Temperature and load current-controlled fan
|
||
|
Protection:
|
Over-temperature, over-voltage, over-current, short-circuit,and reverse connection protection. | ||
|
Charger type: |
Suitable for lead-acid batteries or lithium batteries charging.
|
||
|
Features:
|
1.Automatic multi-stage charging curve for long battery life
2.Intelligent fully automatic charging: obtains the battery status
and switches the charging mode(charge wait/pre-charge/constant current/constant voltage/float charge/ recharge/ full charge) |
||
Charging Curve:
