Product Details:
|
| Model: | UY2500 | Material: | Aluminum Alloy |
|---|---|---|---|
| Input Voltage: | 90V-260V | Power: | 2500Watts |
| Charging Voltage: | 12V, 24V, 36V, 48V, 60V, 72V, Etc. | Charging Current: | 100A, 65A, 45A, 38A, 30A, 23A, Etc. |
| Battery Type: | Lithium-ion/LiFePO4/Lead Acid | Leakage Current:: | <=0.75mA |
| Highlight: | AGM lead acid Forklift battery charger,72V Forklift battery charger,Gel AGV Forklift battery charger |
||
Battery charger parameters
1. Double-sidedFR-4 PCB
2.SAMXON electrolytic capacitors
3. Pure copper transformers
4. Circuit topology: CCM PFC + classical full bridge topology.
|
Model:
|
UY2500
|
Maximum power:
|
2500W
|
|
Housing:
|
Aluminium alloy
|
Size:
|
303x150x90mm
|
|
Input:
|
100-120Vac/200-240Vac
|
Communication:
|
CAN,RS485
|
|
Maximum efficiency:
|
> = 89%
|
Operating temperature:
|
-20 ila 40 ℃
|
|
Storage temperature:
|
-40 ila + 70 ℃
|
Noise:
|
<= 40dB
|
|
Cooling:
|
Smart cooling fan controlled by Temperatur
|
||
|
Protection:
|
1. input under-voltage and over-voltage protection.
2. overheating protection. 3. output empty load protection. 4. output short and reverse protection. 5. output over-current and over-voltage protection. |
||
All of our chargers are tested at least 4 times before leaving the factory and undergo 100% full power aging and baking tests. In order to reach the final result and give our customers the best quality products and services.
Q: How do I choose the charger?
A: To make sure our charging battery is suitable for your package,
Please send us the following information:
(1) battery type (2) number of series units (3) battery pack capacity (AH) (4) maximum charging voltage.
Q: How do you ship the goods and how long does it take to arrive?
A: We often ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping is also optional.
Q: Can I have a sample order?
A: Yes, we can provide an initial sample. But our samples are not free. We need to charge for the samples.
This moped battery charger uses a half-bridge topology and also incorporates an MCU for functional expansion, allowing for personalisation such as communication, charging profile setting and multi-charge mode selection, etc.
