Product Details:
|
| Dimensions:: | 11.93x5.91x3.54" (in Inch) | Weight: | 10.58lbs |
|---|---|---|---|
| Warranty: | 18 Months | Compatible Battery: | Li-ion/ IMR/ INR/ ICR/ Lifepo4/Lead Acid Battery |
| Display: | LED/LCD Display | Input: | 100-120Vac/200-240Vac 47~63Hz |
| Output Voltage: | 12V Dc | Output Current: | 100A |
| Housing Material: | Aluminum Alloy | Color: | Sliver/Black |
| Fan: | Intelligent Temperature Control Fan | Protection: | Output Over Voltage, Output Over Current, Short Circuit, Reverse Polarity, Over-Temperature |
| Efficiency: | 89% | ||
| Highlight: | 100A Bluetooth Battery Charger,PFM Bluetooth Battery Charger,12V 100A Battery Charger |
||
Automatic Multi-stage Charging Curve: The charger utilizes an automatic multi-stage charging curve, optimizing the charging process for maximum battery life. This intelligent feature adjusts the charging parameters at different stages, providing precise and efficient charging.
Current-type Full-Bridge Circuit Topology: Our charger incorporates a current-type full-bridge circuit topology, offering stability, high efficiency, and energy-saving capabilities. This design ensures reliable power conversion and minimizes energy loss during the charging process.
Our Intelligent Bluetooth Battery Charger combines power, intelligence, and portability to provide an efficient charging solution for a wide range of batteries. With its automatic multi-stage charging curve, current-type full-bridge circuit topology, MCU control with PFM technology, intuitive display, durable and portable design, communication options, and comprehensive charging protection, this charger offers convenience and reliability for your charging needs. Experience the advanced features of our Intelligent Bluetooth Battery Charger and enjoy hassle-free charging wherever you go.
|
Type |
Specification |
DC Voltage(Max) |
(CC:A) |
Light Turning(A) |
|||
|
Li-ion |
Lifepo4 |
Lead acid |
Lithium |
Lead acid |
|||
|
UY2500 |
12V 100A |
12.6V/16.8V |
14.6V |
14.7V |
100A |
8%CC |
25%CC |
|
24V 65A |
25.2V/29.4V/33.6V |
29.2V |
29.4V |
65A |
|||
|
36V 45A |
42V/46.2V |
43.8V |
44.1V |
45A |
|||
|
48V 38A |
50.4V/54.6V/58.8V |
54.75V/58.4V |
58.8V |
38A |
|||
|
60V 30A |
63V/67.2V/71.4V |
73V |
73.5V |
30A |
|||
|
72V 23A |
79.8V/84V |
87.6V |
88.2V |
23A |
|||
|
84V 20A |
88.2V |
102.2V |
107.8V |
20A |
|||
|
96V 18A |
100.8V |
109.5V |
117.6V |
18A |
|||
|
108V 16A |
113.4V |
120.45V |
132.3V |
16A |
|||
|
120V 15A |
126V |
131.4V |
147V |
15A |
|||
1. Suitable for lead-acid battery or lithium battery charging, we will configure the appropriate charging curve for your battery.
2. Automatic multi-stage charging curve, which is conducive to extending battery life
3. With charging protection function: over temperature/over voltage/over current/short circuit/reverse protection
4. LED light indicates the current working status
5. Adopt the current type half-bridge circuit topology, stable, efficient and energy-saving
6. MCU control and pulse width modulation (PFM) technology, high efficiency, good stability, low carbon energy, to meet the requirements of different battery charging curves
7. Visual display of voltage and current
8. Aluminum alloy shell, beautiful and strong, durable, handle design, easy to carry, intelligent temperature control fan design
9. Optional communication: CAN,RS485, Bluetooth
