Product Details:
|
| Material: | Aluminum Alloy | Dimension: | 208x120x70mm(8.19x4.72x2.76") |
|---|---|---|---|
| Weight: | 2kg(4.41lbs) | Input: | 100~120Vac/200~240 Vac |
| Frequen: | 47~63Hz | Battery Type: | Lead Acid/Lithium/Li-ion Battery |
| Fan: | Intelligent Cooling Fan Controlled By Temperature | Protection: | Output Over Voltage, Output Over Current, Short Circuit, Reverse Polarity, Over-Temperature |
| Output Voltage: | 12V | Output Current: | 30A |
| DC/AC Connector: | Optional Connector | Communication: | CAN/RS485/Bluetooth |
| Efficiency: | >=88%(full Load) | Warranty: | 18 Months |
| Operating Temperature: | -4℉ To 104℉（-20 To 40 ℃） | Storage Temperature: | -40 To 104℉（-40 To 70 ℃） |
| Highlight: | 12V Lead Acid Battery Charger,30A Lead Acid Battery Charger,12V 30A Battery Charger Intelligent |
||
This 12V30A intelligent charger is suitable for all types of lead acid or lithium batteries.According to your battery,we will set up matched charging curve.
Whether you need to charge golf carts, RVs, forklifts or equipment in the marine and fishing industries, the UY600 Smart Charger will meet your needs. Its portable design allows you to charge anywhere, anytime, without worrying about low battery power. And the rugged aluminum case ensures the charger's reliability and durability in a variety of environments.
What's more, the UY600 smart charger CC/CV ensures that the charging process will not damage the battery through the design of the smart charging curve. This intelligent charging curve adjustment enables full understanding of the battery's charging characteristics and optimal charging mode selection according to its needs. In this way, you can charge with confidence without worrying about shortened battery life or degraded performance.
At the same time, the UY600 Smart Charger can also connect to your phone via Bluetooth, allowing you to easily control the charger. Through the mobile app, you can monitor the charging status, adjust the charging parameters and keep track of the charging progress in real time. Portability, rugged aluminum case, high efficiency charging and intelligent control features make UY600 the best protector for your battery. Invest in a UY600 smart charger to provide all-round care and protection for your battery, making your life more convenient and comfortable.
| Type | Specification | DC Voltage | Charging Current | Light Turning(A) | |||
| Li-ion | Lifepo4 | Lead-acid | Lithium | Lead-acid | |||
|
UY600 |
12V30A | 12.6V/16.8V | 14.6V | 14.7V | 30A | 8% | 25% |
| 24V20A | 25.2V/29.4V/33.6V | 29.2V | 29.4V | 20A | 8% | 25% | |
| 36V12A | 42V/46.2V | 58.42V | 44.1V | 12A | 8% | 25% | |
| 48V10A | 50.4V/54.6V/58.8V | 73V | 58.8V | 10A | 8% | 25% | |
| 60V8A | 63V/67.2V/71.4V | 87.6V | 73.5V | 8A | 8% | 25% | |
| 72V6A | 79.8V/84V | 87.6V | 88.2V | 6A | 8% | 25% | |
| 84V5A | 88.2V/92.4V | 102.2V | 102.9V | 5A | 8% | 25% | |
Product Features
1. AC input: 100-120V /200-240V AC, 47~63Hz
2. Output power:600W
3. Efficiency: >=88%
4. Compatible: Lead-Acid Batteries, LifePo4, and Lithium Batteries
5. Circuit: Classic Half-Bridge Topology
6. Intelligent temperature control fan
7. LED Indicator Lights to Display Current Operational Status
8. Communication: CAN, RS485, Bluetooth
9. Charging Protection Function: Overtemperature/Overvoltage/Overcurrent/Short Circuit/Reverse Polarity Protection
